Panel Saw DS-3200

The Panel-saw-DS-3200 heavy-duty sliding table saw is built for continuous daily production in furniture manufacturing. Its rigid heavy welded frame keeps the whole machine stable during long-hour cutting and reduces vibration effectively. The high-precision aluminum sliding table runs smoothly and effortlessly when feeding large panels.

It adopts double saw blade design, scoring saw works ahead of main saw to prevent surface chipping on veneered boards, leaving smooth and burr-free cutting edges. The saw blade can be electrically lifted and tilted to perform straight cuts and angle bevel cuts flexibly, meeting diverse custom furniture processing needs.

The positioning fence is easy to adjust for consistent sizing on batch cutting. Multiple safety protections are fitted for operator safety. This panel saw works well for MDF, particle board, plywood and solid wood panels, serving as a reliable cutting solution for custom cabinet

Product Description

Large EURO fence with digital readout, high cutting precision
Heavy rigid frame, low vibration, stable continuous operation
Max cutting length 3200mm for large-size panels
Smooth sliding table, clean cutting edge with less chipping
Wide material compatibility: MDF, plywood, solid wood, acrylic

User-friendly operation, boost productivity and save material cost

Bed structure	Heavy Internal Markov structure
Saw blade adjustable angle	45 degrees adjustable
Motor	5.5+1.1kw motor
Lift type	Automatic lifting
Saw blade set	German craft HERO saw blade
Work surface and auxiliary arm	4.3meters push table390 ultra-wide sliding table 190 large scales Enlarged and widened auxiliary workbench Aluminum alloy core puller
Feeding reduction motor	0.75kw Japan precision rack motor
Dual mode switching	Manual and automatic modes can be switched at will
Pressing cylinder	3.2m Cylinder Presser
Sliding structure	With step-by-step lock structure
Lubricating	With oiler
Size	400011001200 mm
Weight	1000 KG
Voltage	380V/3P/60hz
